Hydrogen Gas Sensor Module(MQ-8)

Product Code: SNM014
Category: Sensor Modules
Brand: China

Discount: 0% OFF
Availability: Stock Available

Hydrogen Gas Sensor Module(MQ-8)

177 TK.
/Pcs
- +
Order by Call

Hydrogen Gas Sensor Module(MQ-8)

The sensor module has an MQ-8 as the sensor component and has a protection resistor and an adjustable resistor on-board. The MQ-8 gas sensor is highly sensitive hydrogen and less sensitive to alcohol, and cooking fume. It could be used in gas leakage detecting equipments in family and industry. The resistance of the sensitive component changes as the concentration of the target gas changes.

1. Analog output voltage with concentration, the higher concentration, the higher voltage.
2. Has long service life and reliable stability
3. Rapid response recovery features

They are used in gas leakage detecting equipments in family and industry, are suitable for detecting of Hydrogen (H2), avoid the noise of alcohol and cooking fumes, LPG,CO.

Features:

  1. Using high-quality dual-panel design, with power indicator and TTL signal output instructions.
  2. The switching signal having a DO (TTL) output and analog output AO.
  3. TTL output valid signal is low. ( Low-level signal when the output light can directly connect to the microcontroller or relay module )
  4. The higher the voltage, the concentration of the analog output voltage is higher.
  5. A hydrogen gas detection with good sensitivity.
  6. There are four screw holes for easy positioning.
  7. Has a long life and reliable stability
  8. Rapid response and recovery characteristics


Hydrogen Gas Sensor Module(MQ-8)

Specification:

Input voltage: DC5V
Power consumption (current) : 150 mA
AO output: 0.1-0.3 V (pollution-free)
Highest concentration of voltage: Approx 4 V
Detection range of alcohol: detection range of 10 ~ 1000 PPM

Connection mode:

1. VCC: Positive (5 v)
2. GND: Connect power negative
3. DO: TTL switch signal output
4. AO: Analog signal output

Documents:

MQ-8

How to chose a Gas Sensor

Watch this video it will give you a clear idea about this product.
