Arduino Lilypad

Product Code: ARD009
Brand: China

Discount: 0% OFF
Availability: ( In Stock )

Arduino Lilypad

Tk. 490
- +

Arduino Lilypad

LilyPad Arduino Board

The LilyPad Arduino is a microcontroller board designed for wearable and e-textiles. It can be sewn to fabric and similarly mounted power supplies, sensors and actuators with conductive thread. The board is based on the ATmega168V (the low-power version of the ATmega168). The LilyPad Arduino can be programmed with the Arduino software. The LilyPad Arduino should only be programmed with software versions 0010 or higher. You can program it with earlier versions, but all of the time related functions will be off (twice as slow as they should be).

Features of LilyPad Arduino Board:

  • Microcontroller : ATmega168V or ATmega328V.
  • Operating Voltage: 2.7-5.5 V.
  • Input Voltage : 2.7-5.5 V.
  • Digital I/O Pins : 14 (of which 6 provide PWM output).
  • Analog Input Pins: 6.
  • DC Current per I/O Pin: 40 mA.
  • Flash Memory: 16 KB (of which 2 KB used by bootloader).
  • SRAM : 1 KB.
  • EEPRO : 512 bytes.
  • Clock Speed: 8 MHz.

Applications of LilyPad Arduino Board:

  • It is used in Arduino projects.

Arduino Lilypad

LilyPad Arduino Board

The LilyPad Arduino is a microcontroller board designed for wearable and e-textiles. It can be sewn to fabric and similarly mounted power supplies, sensors and actuators with conductive thread. The board is based on the ATmega168V (the low-power version of the ATmega168). The LilyPad Arduino can be programmed with the Arduino software. The LilyPad Arduino should only be programmed with software versions 0010 or higher. You can program it with earlier versions, but all of the time related functions will be off (twice as slow as they should be).

Features of LilyPad Arduino Board:

  • Microcontroller : ATmega168V or ATmega328V.
  • Operating Voltage: 2.7-5.5 V.
  • Input Voltage : 2.7-5.5 V.
  • Digital I/O Pins : 14 (of which 6 provide PWM output).
  • Analog Input Pins: 6.
  • DC Current per I/O Pin: 40 mA.
  • Flash Memory: 16 KB (of which 2 KB used by bootloader).
  • SRAM : 1 KB.
  • EEPRO : 512 bytes.
  • Clock Speed: 8 MHz.

Applications of LilyPad Arduino Board:

  • It is used in Arduino projects.

Watch this video it will give you a clear idea about this product.
