A single-phase silicon Bridge Rectifier with silver-plated copper leads and a reliable construction utilizing molded plastic case. This bridge rectifier is ideal for printed circuit board.
Documentation
2W10 Full Wave Bridge Rectifier
2W10 Full Wave Bridge Rectifier
Features
- Peak Reverse Voltage (Vrrm): 400V
- Max. RMS Bridge Voltage (Vrms): 280V
- Max. DC Blocking Voltage (Vdc): 400V
- Av. Forward Rectified Current (Io): 2.0A
- Maximum Reverse Current (Ir): 10µA
- Forward Volt Drop per Element (Vf): 1.1V
Watch this video it will give you a clear idea about this product.
