16x2 LCD Display
Product Code: DLC001Category: Displays
16x2 LCD display is basic module and is very commonly used in various devices and circuits.16x2 LCD means it can display 16 characters per line and there are 2 such lines..
16x2 LCD display is basic module and is very commonly used in various devices and circuits.16x2 LCD means it can display 16 characters per line and there are 2 such lines..A liquid-crystal display is a flat-panel display or other electronically modulated optical device that uses the light-modulating properties of liquid crystals. Liquid crystals do not emit light directly, instead using a back light or reflector to produce images in color or monochrome.
|
Pin No. |
Symbol |
Description |
|
1 |
VSS |
Ground |
|
2 |
VDD |
Power supply for logic |
|
3 |
VO |
Contrast Adjustment |
|
4 |
RS |
Data/ Instruction select signal |
|
5 |
R/W |
Read/Write select signal |
|
6 |
E |
Enable signal |
|
7~14 |
DB0~DB7 |
Data bus line |
|
15 |
A |
Power supply for B/L + |
|
16 |
K |
Power supply for B/L - |
-16 X 2 LCD Display With Arduino Connection.
-16 X 2 LCD Display Arduino Connection with i2C Module.
The I2C 1602 LCD module is a 2 line by 16 character display interfaced to an I2C daughter board. The I2C interface only requires 2 data connections, +5 VDC and GND
to operate.
Specifications:
- I2C Address Range 0x20 to 0x27 (Default=0x27, addressable)
- Operating Voltage 5 Vdc
- Contrast-Adjustable by potentiometer on I2c interface
- The device is powered by a single 5Vdc connection.
16x2 LCD display is basic module and is very commonly used in various devices and circuits.16x2 LCD means it can display 16 characters per line and there are 2 such lines..A liquid-crystal display is a flat-panel display or other electronically modulated optical device that uses the light-modulating properties of liquid crystals. Liquid crystals do not emit light directly, instead using a back light or reflector to produce images in color or monochrome.
Pin No. | Symbol | Description |
1 | VSS | Ground |
2 | VDD | Power supply for logic |
3 | VO | Contrast Adjustment |
4 | RS | Data/ Instruction select signal |
5 | R/W | Read/Write select signal |
6 | E | Enable signal |
7~14 | DB0~DB7 | Data bus line |
15 | A | Power supply for B/L + |
16 | K | Power supply for B/L - |
-16 X 2 LCD Display With Arduino Connection.
-16 X 2 LCD Display Arduino Connection with i2C Module.
The I2C 1602 LCD module is a 2 line by 16 character display interfaced to an I2C daughter board. The I2C interface only requires 2 data connections, +5 VDC and GND
to operate.
Specifications:
- I2C Address Range 0x20 to 0x27 (Default=0x27, addressable)
- Operating Voltage 5 Vdc
- Contrast-Adjustable by potentiometer on I2c interface
- The device is powered by a single 5Vdc connection.
Watch this video it will give you a clear idea about this product.
