L293D Motor Driver IC_H-Bridge

Model: CIC020
Brand: China
Product Code:CIC020
Discount:0% OFF
Availability: In Stock

L293D Dual H-Bridge Motor Driver IC

Tk. 40
- +

The L293 and L293D are quadruple high-current half-H drivers. The L293 is designed to provide bidirectional drive currents of up to 1 A at voltages from 4.5 V to 36 V. The L293D is designed to provide bidirectional drive currents of up to 600-mA at voltages from 4.5 V to 36 V. Both devices are designed to drive inductive loads such as relays, solenoids, dc and bipolar stepping motors, as well as other high-current/high-voltage loads in positive-supply applications.

Specifications
  • Supply Voltage Range 4.5V to 36V.
  • 600-mA Output current capability per driver.
  • Separate Input-logic supply.
  • It can drive small DC-geared motors, bipolar stepper motor.
  • Pulsed Current 1.2-A Per Driver.
  • Thermal Shutdown.
  • Internal ESD Protection.
  • High-Noise-Immunity Inputs.

Watch this video it will give you a clear idea about this product.
