GUVA-S12SD Sunlight Ultraviolet Ray Intensity UV Sensor
Product Code: SNM095Category: Sensor Modules
The GUVA-S12SD is a sensor designed to measure ultraviolet (UV) light intensity. Here are the key details about the GUVA-S12SD UV sensor:
Order by Call
GUVA-S12SD Sunlight Ultraviolet Ray Intensity UV Sensor
The GUVA-S12SD is a sensor designed to measure ultraviolet (UV) light intensity. Here are the key details about the GUVA-S12SD UV sensor:
General Features:
- Sensor Type: UV light sensor
- Detection Wavelength: 200-370 nm (UVB and UVA)
- Output Voltage: Analog voltage output proportional to UV intensity
- Supply Voltage: Typically 3.3V to 5V
- Operating Temperature Range: -30°C to +85°C
Electrical Characteristics:
- Peak Sensitivity Wavelength: 254 nm
- Output Range: 0-1V for a typical 5V input
- Current Consumption: Typically around 0.3 mA
- Output Voltage vs. UV Index: The output voltage is proportional to the UV index, allowing easy interfacing with microcontrollers for UV index measurement.
Physical Characteristics:
- Package Type: TO-18 metal can package
- Dimensions: Approximately 5.4 mm diameter and 5 mm height (excluding leads)
Applications:
- UV index measurement
- UV exposure monitoring
- Weather stations
- UV sterilization verification
- Sunburn prevention devices
Pin Configuration:
- Pin 1: Vcc (Supply voltage)
- Pin 2: Ground
- Pin 3: Output (Analog voltage proportional to UV intensity)
GUVA-S12SD Sunlight Ultraviolet Ray Intensity UV Sensor
The GUVA-S12SD is a sensor designed to measure ultraviolet (UV) light intensity. Here are the key details about the GUVA-S12SD UV sensor:
General Features:
- Sensor Type: UV light sensor
- Detection Wavelength: 200-370 nm (UVB and UVA)
- Output Voltage: Analog voltage output proportional to UV intensity
- Supply Voltage: Typically 3.3V to 5V
- Operating Temperature Range: -30°C to +85°C
Electrical Characteristics:
- Peak Sensitivity Wavelength: 254 nm
- Output Range: 0-1V for a typical 5V input
- Current Consumption: Typically around 0.3 mA
- Output Voltage vs. UV Index: The output voltage is proportional to the UV index, allowing easy interfacing with microcontrollers for UV index measurement.
Physical Characteristics:
- Package Type: TO-18 metal can package
- Dimensions: Approximately 5.4 mm diameter and 5 mm height (excluding leads)
Applications:
- UV index measurement
- UV exposure monitoring
- Weather stations
- UV sterilization verification
- Sunburn prevention devices
Pin Configuration:
- Pin 1: Vcc (Supply voltage)
- Pin 2: Ground
- Pin 3: Output (Analog voltage proportional to UV intensity)
Watch this video it will give you a clear idea about this product.
