BTA41600B 40A 600V Triac
Product Code: CMF012Category: MOSFET,IGBT,Diac,Triac,Optocouplers
BTA41600B 40A 600V Triac
BTA41600B 40A 600V Triac
Specifications:
Rated Average On-State Current:40A
Mounting Type:Through Hole
Package Type:TOP3
Maximum Gate Trigger Current:100mA
Repetitive Peak Reverse Voltage:600V
Surge Current Rating:420A
Pin Count:3
Maximum Gate Trigger Voltage:1.3V
Repetitive Peak Forward Blocking Voltage:600V
Maximum Holding Current:80mA
Repetitive Peak Off-State Current:0.005mA
Maximum Operating Temperature:+125 °C
Minimum Operating Temperature:-40 °C
Peak On-State Voltage:1.55V
BTA41600B 40A 600V Triac
Specifications:
Rated Average On-State Current:40A
Mounting Type:Through Hole
Package Type:TOP3
Maximum Gate Trigger Current:100mA
Repetitive Peak Reverse Voltage:600V
Surge Current Rating:420A
Pin Count:3
Maximum Gate Trigger Voltage:1.3V
Repetitive Peak Forward Blocking Voltage:600V
Maximum Holding Current:80mA
Repetitive Peak Off-State Current:0.005mA
Maximum Operating Temperature:+125 °C
Minimum Operating Temperature:-40 °C
Peak On-State Voltage:1.55V
Watch this video it will give you a clear idea about this product.
