Victor DM6234P Handheld Non-contact Laser Digital Photo Tachometer
Product Code: MAO043Category: Analyser/Others Meter
Victor DM6234P Handheld Non-contact Laser Digital Photo Tachometer
Victor DM6234P Handheld Non-contact Laser Digital Photo Tachometer
|
Model |
6236P |
|
|
Specification |
||
|
Type |
Laser + Contact Type |
|
|
Display |
5 digits, LCD display |
|
|
Range |
Laser |
2.5~99999RPM |
|
Surface Speed |
(m/min):1.0~1999.9RPM |
|
|
Contact |
1.0~19999RPM |
|
|
Resolution |
RPM |
0.1RPM |
|
Surface Speed |
(m/min):0.01m/min |
|
|
Accuracy |
±0.05%+1 |
|
|
Time Base |
4MHz quartz crystal |
|
|
Features |
||
|
Display |
5 digits,
LCD display |
|
|
Low battery indication |
√ |
|
|
Data Store |
√ |
|
|
Auto Range |
√ |
|
|
Auto Power off |
√ |
|
|
Max /Min Value |
√ |
|
|
General Information |
||
|
Power Supply |
4×1.5V AA |
|
|
Product Size |
157×65×30mm |
|
|
Product Weight |
Approx:200g |
|
|
Standard Accessories |
Manual, Battery; Reflective tape; Contact wheel; Touch tips |
|
Victor DM6234P Handheld Non-contact Laser Digital Photo Tachometer
Model | 6236P | |
Specification | ||
Type | Laser + Contact Type | |
Display | 5 digits, LCD display | |
Range | Laser | 2.5~99999RPM |
Surface Speed | (m/min):1.0~1999.9RPM | |
Contact | 1.0~19999RPM | |
Resolution | RPM | 0.1RPM |
Surface Speed | (m/min):0.01m/min | |
Accuracy | ±0.05%+1 | |
Time Base | 4MHz quartz crystal | |
Features | ||
Display | 5 digits, LCD display | |
Low battery indication | √ | |
Data Store | √ | |
Auto Range | √ | |
Auto Power off | √ | |
Max /Min Value | √ | |
General Information | ||
Power Supply | 4×1.5V AA | |
Product Size | 157×65×30mm | |
Product Weight | Approx:200g | |
Standard Accessories | Manual, Battery; Reflective tape; Contact wheel; Touch tips | |
Watch this video it will give you a clear idea about this product.
