Microwave Radar Sensor Module
Product Code: SNM003Category: Sensor Modules
Microwave Radar Sensor Module
Description:
This little board is a Doppler radar microwave motion sensor module. It detects motion in a 360-degree directional range and can serve as an alternative to a PIR motion sensor. Use it to pick up any moving objects, animals, or people. It can be hooked up to an output to create a DIY security system, program to wake up a device or create a wicked Halloween decoration (tutorial below!).
Features:
- Built-in microwave frequency transmitter/receiver/mixer
- Doppler Radar capabilities
- 360-degree directional detection range
- Dimensions: 17.3 x 35.9 mm
Specifications:
- Operating Voltage: 4V - 28V, 5V - 12V (recommended)
- Operating Current: 2.8mA (typical); 3mA (max)
- Detection Distance: 5~9m
- Transmitting Power: 20mW (typical); 30mW (max)
- Output voltage: 3.2V~3.4V
- Operating Temperature: -20~80 ℃
- Storage Temperature: -40~100 ℃
Pin Definition:
- 3V3: 3.3V power output, it can be used as a reference voltage or as a low current (less than 100mA) 3.3V power supply.
- GND: Ground
- OUT: Control output; the moving object will be detected when it outputs high level 3.3V
- VIN: 4-28V Input voltage
- CDS: CDS photodetector output. NOTE: Photodetector is not installed on the board, it can be added by the user for daytime/nighttime detection.
Adjustment Components:
- C-TM: Regulates the repeat trigger time, the default time is 2s. It will extend the repeat trigger time if you add the capacitor value. Eg. Pin 3 of the IC emits a frequency (f), and the trigger time in seconds is given by (1/f) * 32678
- R-GN: The default detection range is 7m, it will became smaller with the resistor. 1M resistor equal to 5m.
- R-CDS: Internal VCC and internal 1M Ohm resistor in parallel connection to the CDS pin (RCWL-9196 pin 9). Connects with a photoresistor (not installed on the board, can be added by the user).
How it works:
Doppler radar measures the Doppler effect, or an increase or decrease in the frequency of sound, light, or other waves as the source and observer move toward or away from each other.
Microwaves are electromagnetic radiations that are sent by a transmitter. They get reflected off of objects and based on the object's velocity, the frequency of the waves will be altered. The receiver will then detect the reflected waves and calculate the difference in the transmitted and received waves’ frequency. This difference is what is used for the board to sense motion.
Description:
This little board is a Doppler radar microwave motion sensor module. It detects motion in a 360-degree directional range and can serve as an alternative to a PIR motion sensor. Use it to pick up any moving objects, animals, or people. It can be hooked up to an output to create a DIY security system, program to wake up a device or create a wicked Halloween decoration (tutorial below!).
Features:
- Built-in microwave frequency transmitter/receiver/mixer
- Doppler Radar capabilities
- 360-degree directional detection range
- Dimensions: 17.3 x 35.9 mm
Specifications:
- Operating Voltage: 4V - 28V, 5V - 12V (recommended)
- Operating Current: 2.8mA (typical); 3mA (max)
- Detection Distance: 5~9m
- Transmitting Power: 20mW (typical); 30mW (max)
- Output voltage: 3.2V~3.4V
- Operating Temperature: -20~80 ℃
- Storage Temperature: -40~100 ℃
Pin Definition:
- 3V3: 3.3V power output, it can be used as a reference voltage or as a low current (less than 100mA) 3.3V power supply.
- GND: Ground
- OUT: Control output; the moving object will be detected when it outputs high level 3.3V
- VIN: 4-28V Input voltage
- CDS: CDS photodetector output. NOTE: Photodetector is not installed on the board, it can be added by the user for daytime/nighttime detection.
Adjustment Components:
- C-TM: Regulates the repeat trigger time, the default time is 2s. It will extend the repeat trigger time if you add the capacitor value. Eg. Pin 3 of the IC emits a frequency (f), and the trigger time in seconds is given by (1/f) * 32678
- R-GN: The default detection range is 7m, it will became smaller with the resistor. 1M resistor equal to 5m.
- R-CDS: Internal VCC and internal 1M Ohm resistor in parallel connection to the CDS pin (RCWL-9196 pin 9). Connects with a photoresistor (not installed on the board, can be added by the user).
How it works:
Doppler radar measures the Doppler effect, or an increase or decrease in the frequency of sound, light, or other waves as the source and observer move toward or away from each other.
Microwaves are electromagnetic radiations that are sent by a transmitter. They get reflected off of objects and based on the object's velocity, the frequency of the waves will be altered. The receiver will then detect the reflected waves and calculate the difference in the transmitted and received waves’ frequency. This difference is what is used for the board to sense motion.
Watch this video it will give you a clear idea about this product.
