Function Signal Generator Module_XR2206
Product Code: MSG001Category: Other Modules
Function Signal Generator Module_XR2206
Order by Call
Function Signal Generator Module_XR2206
Specification:
- Voltage Supply: 9-12V DC Input
- Waveforms: Square, Sine & Triangle
- Impedance: 600 Ohm + 10%
- Frequency: 1Hz-1MHz
- Sine Wave
- Amplitude: 0-3V at 9V DC Input
- Distortion: Less than 1% (at 1KHz)
- Flatness: +0.05dB 1Hz - 100kHz
Square Wave
- Amplitude: 8V (no load) at 9V DC Input
- Rise Time: Less than 50ns (at 1KHz)
- Fall Time: Less than 30ns (at 1KHz)
- Symmetry: Less than 5% (at 1KHz)
Triangle Wave
- Amplitude: 0-3V at 9V DC Input
- Linearity: Less than 1% (up to 100KHz) 10mA
Package Included:
- 1pc * Function Signal Generator Module Kit
Function Signal Generator Module_XR2206
Specification:
- Voltage Supply: 9-12V DC Input
- Waveforms: Square, Sine & Triangle
- Impedance: 600 Ohm + 10%
- Frequency: 1Hz-1MHz
- Sine Wave
- Amplitude: 0-3V at 9V DC Input
- Distortion: Less than 1% (at 1KHz)
- Flatness: +0.05dB 1Hz - 100kHz
Square Wave
- Amplitude: 8V (no load) at 9V DC Input
- Rise Time: Less than 50ns (at 1KHz)
- Fall Time: Less than 30ns (at 1KHz)
- Symmetry: Less than 5% (at 1KHz)
Triangle Wave
- Amplitude: 0-3V at 9V DC Input
- Linearity: Less than 1% (up to 100KHz) 10mA
Package Included:
- 1pc * Function Signal Generator Module Kit
Watch this video it will give you a clear idea about this product.
