FNIRSl 2C53T Handheld 3-in-1 50MHz Oscilloscope
Product Code: MOS018Category: Oscilloscope
FNIRSl 2C53T Handheld 3-in-1 50MHz Oscilloscope
FNIRSl 2C53T Handheld
3-in-1 50MHz Oscilloscope
Description:
The FNIRSI 2C53T is
an advanced, portable 3-in-1 device that seamlessly integrates a dual-channel
digital oscilloscope, a 4.5-digit True RMS multimeter, and a versatile signal
generator. Designed for professionals and hobbyists alike, this compact tool
offers precision, versatility, and convenience in a single handheld unit.
Key Features:
· Dual-Channel Oscilloscope: 50MHz bandwidth with a 250MSa/s sampling
rate, 1kpts memory depth, and ±400V input protection. Supports XY, YT, and
scrolling modes, along with FFT analysis and 8 math operations.
· True RMS Multimeter: 4.5-digit display with 19999 counts, capable
of measuring AC/DC voltage, current, resistance, capacitance, diode testing,
and continuity checks.
· Signal Generator: Built-in DDS function generator outputs 13
waveform types up to 50kHz, with adjustable frequency, amplitude, and duty
cycle.
· User-Friendly Interface: 2.8-inch TFT color display (320×240
resolution) provides clear visuals. Features include auto measurements, cursor
measurements, and waveform storage.
· Portable and Durable: Compact design (167×89×35mm) with a sturdy
build, weighing only 300g. Equipped with a 3000mAh rechargeable lithium battery
offering up to 6 hours of standby time.
Specifications:
Oscilloscope:
· Bandwidth: 50MHz
· Channels: 2
· Sampling Rate: 250MSa/s
· Memory Depth: 1kpts
· Input Impedance: 1MΩ
· Vertical Sensitivity: 10mV/div–10V/div
· Time Base: 10ns/div–20s/div
· Trigger Types: Auto, Normal, Single
Multimeter:
· Display Count: 19999
· Measurements: AC/DC Voltage, Current,
Resistance, Capacitance, Diode, Continuity
· Signal Generator:
· Waveforms: 13 types
· Frequency Range: Up to 50kHz
· Output Voltage: 0–3V
· General:
· Display: 2.8-inch TFT Color Screen (320×240)
· Battery: 3000mAh Rechargeable Lithium Battery
· Charging: USB Type-C (5V/1A)
· Dimensions: 167×89×35mm
· Weight: 300g
· Languages: English, Chinese
FNIRSl 2C53T Handheld 3-in-1 50MHz Oscilloscope
Description:
The FNIRSI 2C53T is an advanced, portable 3-in-1 device that seamlessly integrates a dual-channel digital oscilloscope, a 4.5-digit True RMS multimeter, and a versatile signal generator. Designed for professionals and hobbyists alike, this compact tool offers precision, versatility, and convenience in a single handheld unit.
Key Features:
· Dual-Channel Oscilloscope: 50MHz bandwidth with a 250MSa/s sampling rate, 1kpts memory depth, and ±400V input protection. Supports XY, YT, and scrolling modes, along with FFT analysis and 8 math operations.
· True RMS Multimeter: 4.5-digit display with 19999 counts, capable of measuring AC/DC voltage, current, resistance, capacitance, diode testing, and continuity checks.
· Signal Generator: Built-in DDS function generator outputs 13 waveform types up to 50kHz, with adjustable frequency, amplitude, and duty cycle.
· User-Friendly Interface: 2.8-inch TFT color display (320×240 resolution) provides clear visuals. Features include auto measurements, cursor measurements, and waveform storage.
· Portable and Durable: Compact design (167×89×35mm) with a sturdy build, weighing only 300g. Equipped with a 3000mAh rechargeable lithium battery offering up to 6 hours of standby time.
Specifications:
Oscilloscope:
· Bandwidth: 50MHz
· Channels: 2
· Sampling Rate: 250MSa/s
· Memory Depth: 1kpts
· Input Impedance: 1MΩ
· Vertical Sensitivity: 10mV/div–10V/div
· Time Base: 10ns/div–20s/div
· Trigger Types: Auto, Normal, Single
Multimeter:
· Display Count: 19999
· Measurements: AC/DC Voltage, Current, Resistance, Capacitance, Diode, Continuity
· Signal Generator:
· Waveforms: 13 types
· Frequency Range: Up to 50kHz
· Output Voltage: 0–3V
· General:
· Display: 2.8-inch TFT Color Screen (320×240)
· Battery: 3000mAh Rechargeable Lithium Battery
· Charging: USB Type-C (5V/1A)
· Dimensions: 167×89×35mm
· Weight: 300g
· Languages: English, Chinese
Watch this video it will give you a clear idea about this product.
