Float Switch - Water Level Sensor
Product Code: SNM034Category: Sensor Modules
Float Switch - Water Level Sensor
Float Switch - Water Level Sensor
A float switch is a device used to sense the level of liquid within a tank.
The switch may actuate a pump, an indicator, an alarm, or other device.
Use them with hydroponics, saltwater tank, freshwater tank, gardening, aquariums for power head control, pet bowls, fish tanks, filtration, heating, pumps, ponds, basement alarms, boats, air condition drain pans, pressure washers, carpet cleaning mach, reef aquarium, fluid control, ice machines, coffee pots, marine, automotive, automobiles, tropical fish tanks, evaporator coils, condensation line, in relays, or what ever your project may be.
It can be easily converted from normally open to normally close by inverting the float.
Technical Specifications:
Max contact rating:10W
Max switch voltage: AC/DC100V
Max switch current: 0.5A
Max breakdown voltage: AC/DC220V
Max Ccarry current: 1.0A;
Max contact resistance: 100mΩ;
Working temperature: -10 ~ 65 °
Float ball material: P.P
Float body material:plastic
Float ball size: 19 x 16mm(D*H)
Screw thread diameter: 8mm
Product Dimensions LxWxH (mm):
Float ball size: 19 x 16mm(D*H)
Screw thread diameter: 8mm
Package Includes:
1x water level sensor switch
Float Switch - Water Level Sensor
A float switch is a device used to sense the level of liquid within a tank.
The switch may actuate a pump, an indicator, an alarm, or other device.
Use them with hydroponics, saltwater tank, freshwater tank, gardening, aquariums for power head control, pet bowls, fish tanks, filtration, heating, pumps, ponds, basement alarms, boats, air condition drain pans, pressure washers, carpet cleaning mach, reef aquarium, fluid control, ice machines, coffee pots, marine, automotive, automobiles, tropical fish tanks, evaporator coils, condensation line, in relays, or what ever your project may be.
It can be easily converted from normally open to normally close by inverting the float.
Technical Specifications:
Max contact rating:10W
Max switch voltage: AC/DC100V
Max switch current: 0.5A
Max breakdown voltage: AC/DC220V
Max Ccarry current: 1.0A;
Max contact resistance: 100mΩ;
Working temperature: -10 ~ 65 °
Float ball material: P.P
Float body material:plastic
Float ball size: 19 x 16mm(D*H)
Screw thread diameter: 8mm
Product Dimensions LxWxH (mm):
Float ball size: 19 x 16mm(D*H)
Screw thread diameter: 8mm
Package Includes:
1x water level sensor switch
Watch this video it will give you a clear idea about this product.
